Specifications:

Thermal Cycling Technology
High performance active heating and cooling using quality Peltier elements x8  and precision sensors x4

Temperature Range
4°C – 99°C
Temperature Accuracy:
±0.25°C of set temperature, 1 minute after target

Temperature Uniformity:
±0.5°C, 30 seconds after target

Temperature Resolution:
0.1°C increments

Heating / Cooling Rate:
3°C/sec maximum (block)

Well Configuration  Programmable:
96-Well block supporting: 0.2 mL tubes or strip tubes with flat or domed caps;
96-well high-or low skirt plates with strip caps, adhesive cover, or oil overlay

Linear Thermal Gradient*:
Programmable 0–20°C across block width (12 wells)

Condensation control:
Automatic utilising applied pressure heated lid Controllable

Heated Lid Temperature Range:
60°C – 110°C

Dimensions:
Width:  180mm (7”)
Depth:  285mm (11.2”); 350mm (13.8”) including cables
Height:  190mm (7.5”) lid closed; 340mm (13.4”) lid open

Weight:
5.5kg (11 lbs)

Colour:
White on black

Electrical:
100–240 VAC @ 4 Amp (50/60 Hz) Automatic voltage sense Standard IEC Inlet plug

External Connectivity Interface:
USB1.1 interface to Windows XP/Vista based PC USB host port - File transfer to and from USB memory stick - mouse/keyboard connection - printer (future software release)

Internal Interface (optional):
Embedded graphical controller with 7” widescreen touch sensitive colour backlit display

Software:
Supplied with unlimited user license
Free upgrades available via web download

Functionality:
Touch Down / Up, Long Range, Linear Thermal Gradient*, Program Pauses, Temperature Graphing, Temperature Logging (PC only)
User Accounts, Profile Load and Saving, Manual Mode
USB File Transfer

Included Accessories:
Power Cable
User Manual
Touch Screen Stylus
